PORTOWER product

E681 -24Y4C

E681 series three-layer Ethernet switch (hereinafter referred to as "E681") is a high-performance, high-density 10GE/25GE/100GE switch built with Ethernet switching chip CTC8180. The E681 is equipped with CentecOS system software, supports mainstream protocol standards and applications, and can be easily and quickly deployed and managed.

Standard 1U 19 '' rack equipment

24 x 25GE SFP28 ports

4 x 100GE QSFP28 ports

Plug and unplug redundant fans

Pluggable dual power supply (default configuration dual AC power supply)

Request a quotation: Some commercial or technical fields (material, certification, voltage, price) are not present in the source records. PORTOWER can confirm them for your project.

Pricing, availability, certification and compatibility are confirmed during quotation.

Request a quote →

Product advantages

Designed for practical deployment.

Source-grounded

Product details are retained from the authorized source package.

Fit review

Share your requirements and our team will validate the configuration.

Commercial clarity

Lead time, warranty and final terms are confirmed before order.

Technical specifications

modelE681 -24Y4C

Dimensions(L*W*H)4.4 x 44.2 x 45.1 cm (1.7 x 17.4 x 17.8 in.)

Weight8.35 kg

Management interfaceOne RJ45 type serial port, one RJ45 out-of-band management port, and one standard USB port

Interface24个40GbE QSFP+端口，4个100GbE QSFP28端口

Switching Capacity2.88 Tbps

Packet Forward Speed2142.7 Mpps

Operating Temperature0 to 45 ºC

Storage Temperature-40 to 70 ºC

Storage Humidity0 to 95% (non-condensing)

包时延(ns)700 ns

CPU龙芯 LS2K 1000

Memory2GB

Flash512MB

包缓存36MB

Power InputAC 100-240V 50/60Hz Maximum voltage: 90 ~ 264V; 47~63Hz Maximum voltage range: -40 ~ -72V Maximum voltage range: 180 ~ 300V

Dual power inputYES

Power hot-plugYES

风扇风向前后风向

风扇数量4

风扇热插拔特性支持

Typical power consumption95W

Maximum Power Consumption130W

MTBF(hours)>198000

MTBF(years)>22.6

Applications

Tell us about the environment.

Campus, data-center, industrial, edge and project deployments can be scoped through the RFQ workflow.

Documents

Product documents and support

Datasheets, lifecycle information and software links are provided where the source package includes them.
