EMS

EMS. Technical specifications and quotation support are available from PORTOWER.

Request a quotation: Some commercial or technical fields (dimensions, power, material, certification, voltage, performance, price) are not present in the source records. PORTOWER can confirm them for your project.

Pricing, availability, certification and compatibility are confirmed during quotation.

Request a quote →

Product advantages

Designed for practical deployment.

Source-grounded

Product details are retained from the authorized source package.

Fit review

Share your requirements and our team will validate the configuration.

Commercial clarity

Lead time, warranty and final terms are confirmed before order.

Technical specifications

product_modelRFCOM-508 | RFCOM-708

cpuRK3568J, 32-bit

operating_systemDebian

storageDDR4: 4GB; EMMC: 32GB; SSD (256/512/1024GB optional)

ledSystem: Power*1, RUN*1 LAN: 1000M*3 (Link*1, Act*1)

othersRTC/Hardware Watchdog

screenWithout screen | With screen

weight1.53kg (without ear hooks) | 2.43kg (without ear hooks)

size252mm*159mm*33mm | 276mm*190mm*40mm

input_voltageDC:16-32V | DC:16-32V

static_power_consumption< 5W | < 7W

power_consumption_full_load< 10W | < 12W

operating_environment_temperature-20 to 65℃ | -20 to 60℃

relative_humidity_of_working_environment_non_condensing5% to 95% (non-condensing) | 5% to 95% (non-condensing)

esdGB/T 17626.2-2018 Contact 6KV, air 8KV

eftGB/T 17626.4-2018 Class 3

sugreGB/T 17626.5-2018 Class 3

re_ce_rs_csGB/T 9254.1-2021 Class A

communication_protocolSupports Modbus RTU communication protocol Supports Modbus TCP communication protocol Supports IEC104 communication protocol

communication_machine_softwareSupports data processing and protocol conversion Supports modification of network port sequence and IP configuration Supports modification of 485 configuration baud rate, stop bit and parity bit, and firmware upgrade

security_featuresSupports user hierarchical management and password protection

web_functionalitySupports management machine IP search Supports IP modification Supports login with accounts of different permissions Supports configuration import Supports configuration call-up Supports configuration export, including COM configuration export/TCP configuration export/point table configuration export Supports operation monitoring

modelEMS

Applications

Tell us about the environment.

Campus, data-center, industrial, edge and project deployments can be scoped through the RFQ workflow.

Documents

Product documents and support

Datasheets, lifecycle information and software links are provided where the source package includes them.
