RFCOM-1008 AI Intelligent Controller

RFCOM-1008 is developed and designed based on NVIDIA Jetson Orin Nano, with a computing power of 20/40TOPS and a power consumption as low as 10-20w. Equipped with a 6-core ARM Cort

Request a quotation: Some commercial or technical fields (dimensions, weight, power, material, certification, voltage, performance, price) are not present in the source records. PORTOWER can confirm them for your project.

Pricing, availability, certification and compatibility are confirmed during quotation.

Request a quote →

Product advantages

Designed for practical deployment.

01

Source-grounded

Product details are retained from the authorized source package.

02

Fit review

Share your requirements and our team will validate the configuration.

03

Commercial clarity

Lead time, warranty and final terms are confirmed before order.

Technical specifications

Technical specifications

hardware_configurationAI性能 | 20TOPS（S001），40TOPS（S002）
cpu512*Cores NVIDIA Ampere architecture GPU with 16*Tensor Cores(S001) 1024*Cores NVIDIA Ampere architecture GPU with 32*Tensor Cores(S002)
specification板载 4GB 64bit LPDDR5 34GB/s(S001)/8GB 128 bit LPDDR5 68GB/s(S002)
extended_interface1*M.2 3052 B-Key, with SIM card slot, supporting 4G LTE or 5G NR wireless function module 1*M.2 2280 M-Key, supporting NVMe high-speed memory card 1*Mini PCIe expansion slot
video_codecVideo coding 1080p30 supported by 1-2 CPU cores Video decoding H.265: 1*4K60 | 2*4K30 | 4*4K30 | 5*1080p60 | 11*1080p30;
audioRealtek ALC5640 audio, supporting stereo channel output
ethernetSupports 2*LAN 10/100/1000Mbps (default support for 2 ordinary Gigabit networks, 2 POE channels are optional)
store1*M.2 2280 M-Key, supporting NVMe ultra-high-speed solid-state storage; 1*Micro SD card
camera_interfaceSupports 2*4 lane Mipi (22 pins) by default, and optionally supports 4*GMSL interface
dio4-bit 2.5KV光电隔离 DI（TTL信号），4-bit 2.5KV光电隔离 DO（TTL信号）；2*2.5KV光电隔离 RS232和 RS485 /422；
i_o_interfaceSupports 2*RJ45 (with 2*POE optional); 1*HDMI; 2*USB3.2(Gen2 10Gbps,TypeA); 2*USB2.0 (Type A); 1*Line out; 1*Iso.RS232+1*Iso.RS485/422(2*5pin Phoenix terminal); 2*Iso.CAN (1 DB9, where one isolation is optional); 1*8-bit Iso.DIO (2* 6-pin Phoenix terminal); 1*SIM card slot; 1*Mico SD card slot; 4*ANT;
indicator_lightIndicator light | 1*Power LED(on the Power button), 1* operation light
switchControl switch | 1* Power key w/LED, 1*RST key; 1*REV button;
power_supplyPower Supply requirements | DC 9~36V wide voltage DC input, 3-pin 3.81mm pitch Phoenix socket, overvoltage and overcurrent reverse connection protection; TDP: TBD (Jetson NX Orin 8GB); DC 12V output maximum 3A, 4-pin 3.5mm pitch Phoenix socket
operating_systemOperating system | Linux Ubuntu 18.04和 20.04 with JetPack
mechanical_parametersConstruction of | Fanless heat dissipation housing, SGCC box
color_tdGraphite black + Granite Gray
size(L*W*H)：Main box ：190*145*68mm
environmentOperating temperature | -20℃ to 60℃ (air flow)
storage_temperature_storage_humidity-40°C~85°C/ 10~90%@40°C, No condensation
vibration5grms/5~500Hz/ Random/Working state (SSD); 1grms/5~500Hz/ Random/Working State (HDD)
impact50g peak acceleration (sustained for 11ms)(SSD); 20g peak acceleration (for 11ms)(HDD)
emc_certificationCE/FCC Class A
modelRFCOM-1008 AI Intelligent Controller
